BirdDog Eyes P200B 1080P 30x Full NDI PTZ Camera w/Sony Sensor & HDMI/3G-SDI (Black)

SKU: BDP200B

BDP200B | Eyes P200 1080P Full NDI PTZ Camera w/Sony Sensor & HDMI/3G-SDI (Black)
BDP200B PTZ camera utilizes BirdDog's custom NDI silicon chip and leverages an impressive Sony CMOS backlit sensor and full Sony Image Module.

Designed for serious production the image quality of P200 is best in class. Built on a true Sony Image module with Sony CMOS backlit sensor, P200 has super fast focus, incredibly sharp images, and amazingly fast zoom. P200 has frame rates up to 1080p60, 30x optical zoom, and outputs SDI, HDMI, and NDI simultaneously. 3.5mm audio connectors allow P200 to work with BirdDog Comms, the world's first NDI audio intercom platform. Comms is a Windows 10 application that can run on any Windows 10 compatible computer, laptop, or surface for a touch screen experience.

P200 has been designed for the most demanding on image quality. The superior optics make P200 perfect for Sports, Broadcast, Live Event Production, IMAG, Education, and any other application where quality matters. P200 can also be used as a traditional PTZ camera with SDI, RS422, RS485, and RS232 control allowing you to move into the world of NDI when you are ready.

CAMERA

Image Sensor

1 / 2.8 inch CMOS 2.13MP

Lens

4.3-129mm

Optical Zoom

30x

Digital Zoom

12x

Horizontal Angle of View

63.7o(W) – 2.3o(T)

Aperture

F1.6(W) – F4.7 (T)

Min. Illumination

Color: 0.01 lux (F1.6,AGC on,1/30s, High sensitive mode), 0.1 lux(F1.6,AGC on,1/30s, Normal sensitive mode)

Shutter Speed

1/1 – 1/10000s

Focus

Auto, Push, Manual

White Balance

Auto,Indoor,Outdoor,Manual,OPW ,ATW

Exposure

Auto,Manual,Shutter/Iris Priority

Backlight Comensation

YES



MECHANICAL

Pan Movement

Horizontal:±350 degrees continuous pan (Zoom Adaptive Speed Range: 0.05°ã€œ100°/S )

Tilt Movement

Vertical:+90 degrees to -30 degrees (Zoom Adaptive Speed Range: 0.05°ã€œ50°/S)

Preset Positions

128 (Speed adjustable: Up to 150o/s)

Preset Speed

0-5 Level adjustable

Environmental

Indoor



VIDEO INTERFACE

Video Output

NDI/HDMI/SDI

Video Formats

1080P 60, 59.94, 50, 29.97, 25

1080i 60, 59.94, 50

720p 60, 59.94, 50, 29.97, 25

Audio I/O

3.5mm Audio In (Stereo)

3.5mm Audio Out (Stereo)



CONTROL INTERFACE

IP PTZ Control

NDI Control (auto configuring)

Serial PTZ Control

2x RJ45: RS232/RS422/RS485

Serial Control Protocol

VISCA / Pelco D



POWER & DIMENSIONS

Operating Temperature

-10 - +50 (oC)

Operating Humidity

=< 80%

Power Input

12vDCm, PoE+ (IEEE 802.3at)

Dimensions

160x178x220mm

Weight

2.0kg



NETWORK

Video Compression

Full NDI – i-frame high quality low latency NDI for production

Network Protocol

NDI – Discovery, configuration and control

Web Control interface

Full control via Web/Mobile UI including Scene presets

  • 1x BirdDog Eyes P200
  • 1x IR Remote Controller (3V CR2032 Coin Lithium Battery Required)
  • 1x Camera Power Adaptor & Power Cord
  • 1x Bag of Mounting Screws
  • 1x RJ45 to RS232 Extension Cable
  • 1x RJ45 to RS422 Extension Cable
