MRMC QRS-01 2-Meter Simple track solution for medium payloads and low speed moves
COST EFFECTIVE, MODULAR TRACK SYSTEM
The Quiet Rail System (QRS-1) is a cost-effective, modular track designed for studio, event and mixed production environments. The QRS1 is an ideal solution for customers looking for either fixed or portable setups and works equally as well with an MRMC robotic head, or 3rd party PTZ.
MADE FOR LIVE
The multi-functional QRS-1 is an extremely quiet system ideal for a range of scenarios including studios and broadcast, as well as live streaming for events, house of worship or other similar applications. The system comes with a variety of mounting options, such as the floor, ceiling or wall. There is also an encoded option with FreeD output capabilities coming soon.
KEY FEATURES
The Quiet Rail System (QRS-1) is a cost-effective, modular track designed for studio, event and mixed production environments. The QRS1 is an ideal solution for customers looking for either fixed or portable setups and works equally as well with an MRMC robotic head, or 3rd party PTZ.
MADE FOR LIVE
The multi-functional QRS-1 is an extremely quiet system ideal for a range of scenarios including studios and broadcast, as well as live streaming for events, house of worship or other similar applications. The system comes with a variety of mounting options, such as the floor, ceiling or wall. There is also an encoded option with FreeD output capabilities coming soon.
KEY FEATURES
- Extremely Quiet
- Modular Design
- Datum Magnet coordination
- MHC and Flair compatible
- Manual or algorithmic control
PAYLOAD AND SIZE
MAX. PAYLOAD
MAX. SPEED
MAX. ACCELERATION/DECELERATION
RAIL RANGE OF MOTION
RANGE OF FEET ADJUSTMENT
TEMP. RANGE
HUMIDITY TOLERANCE
CONNECTIVITY & POWER
COMMUNICATION INTERFACE
OPERATING VOLTAGE
MAX. PAYLOAD
- 20kg
- 400mm
MAX. SPEED
- 40cm/s
MAX. ACCELERATION/DECELERATION
- 40cm/s²
RAIL RANGE OF MOTION
- Subject to length in sections (2m, 3m and multiples thereof)
RANGE OF FEET ADJUSTMENT
- 20mm
TEMP. RANGE
- 0 - 40°C Range
HUMIDITY TOLERANCE
- RH Non-Condensing 0-85%
CONNECTIVITY & POWER
COMMUNICATION INTERFACE
- Ethernet MRC protocol
OPERATING VOLTAGE
- Motor 12v/ Uni Box 24v
