Glyph Studio RAID 16 TB

SKU: GLSTURAID16TB

Designed with the ability to edit and playback multiple audio and HD video streams, the StudioRAID 16TB 2-Bay USB 3.0 RAID Array (2 x 8TB) from Glyph Technologies is a production-grade external RAID array that connects to your host system using its one micro-USB 3.0 port, two FireWire 800 ports, or one eSATA port at speeds up to 360 MB/s. The StudioRAID is equipped with two 3.5" drive bays and a total capacity of 16TB, which is configured as 2 x 8TB 7200 rpm hard drives. To help facilitate its functionality within a production environment, the StudioRAID comes pre-configured as a RAID 0, which helps enhance performance by spreading data across two drives and is also compatible with RAID 1, which offers data redundancy. For those who do not require a RAID, JBOD and SPAN are also supported. This array is powered by an internal international auto-switching power supply that operates at 100-240 VAC at 50/60 Hz, is cooled with an intelligent quiet fan, uses disk health monitoring, and is constructed from a scratch-resistant black powder-coated aluminum chassis with a brushed stainless steel face plate. While the StudioRAID comes pre-formatted for HFS+ Journaled for Mac, it may also be used with Windows, Linux, Unix, and BSD after a simple reformat. Included is a micro-USB 3.0 cable, a FireWire 800 cable, and a power cable. It is protected by hardware, data recovery, and advance replacement warranties.



General Features

Achieve Speeds up to 360 MB/s

The StudioRAID is a reliable hardware RAID array with USB 3.0, FireWire 800, and eSATA connectivity, supporting RAID 0, 1, JBOD, and SPAN modes. A temperature-controlled intelligent fan complements its auto-sensing power supply for a combination of speed and reliability

RAID 0 and RAID 1

RAID 0 (striping) increases the performance of the drive system by spreading the data across two drives. RAID 0 is designed for editing video, working with huge graphics files, sound libraries, and streaming instruments that play hundreds of samples simultaneously. RAID 0 is the default shipping drive mode.

RAID 1 offers data redundancy and real-time backup by writing the same data to the two hard drives at the same time. Should a drive failure happen, data is still available on the remaining drive

Time Machine Compatible

The Glyph StudioRAID comes pre-formatted as HFS+ with Journaling and is Time Machine compatible out of the box. A simple reformat is all it takes for the StudioRAID to work with Windows systems

Smart, Quiet, & Efficient Cooling

The StudioRAID uses a temperature-controlled fan that helps keep it quiet while still offering proper cooling. The case is designed with front-panel ventilation holes to draw cool air in, while exhausting warm air out the back

Universal & Auto-Sensing Internal Power

External power adapters are easily misplaced, accidentally unplugged, and take up valuable outlet space. The StudioRAID uses an industry-standard power cord and a pro-quality internal power supply for efficient and reliable power. The StudioRAID will also sense when you connect over USB or FireWire, and automatically power on

Disk Health Monitoring

The StudioRAID includes disk monitoring features designed to keep your data safe. Should your drive begin to exhibit behavior indicating an imminent drive failure, the multi-function LED will alert you via a red light. Additionally, to safeguard against accidentally powering off your StudioRAID, the intelligent power switch must be held for 3 seconds to power off the drive

Rackmount Kit Available

The GPT Rackmount Kit transforms your StudioRAID into a rackmount hard drive. The rackmount kit accessory is capable of mounting one or two Studio-series drives

Content Creation Applications

Final Cut Pro
Avid Media Composer
Adobe Premiere
Digidesign Pro Tools
Steinberg Nuendo and Cubase
Apple Logic
MOTU Digital Performer
Cakewalk Sonar
Sony Vegas

Interface

  • (1) USB 3.0
  • (2) FireWire 800
  • (1) eSATA
  • (Compatible with USB 2.0)

Transfer Rate

  • Up to 360 MB/s

Capacity

  • 2TB
  • 4TB
  • 6TB
  • 8TB
  • 10TB
  • 12TB
  • 16TB

 Drive Speed

7,200 RPM

RAID Modes

  • RAID 0
  • RAID 1
  • SPAN
  • JBOD
  • (No Software Required)

Cooling

  • Intelligent quiet fan

Power

  • Internal Universal
  • 100-240v
  • 50/60 Hz

Mac + Windows

Formatted for MAC, compatible with Windows

Dimensions

3.1” x 8.6” x 6.4”
79 x 217 x 164 mm

In The Box

  • StudioRAID hard drive
  • Glyph USB 3.0 cable
  • Glyph FireWire 800 cable
  • IEC Power Cable

Warranty

(3) year hardware

(2) year lvl 1 recovery

(1) year adv replacement
